DESCRIPTION
OF THE MACHINE
10
3.3 OPERATING PARTS
01
Technical Data Plate
11
Sensor
in the pan
02
Plate serial no.
12
Steam vent (mod.CBTG)
03
Emergency button
13
Steam pressure gauge (mod.CBTV)
04
Control panel
14
Steam safety valve (mod.CBTV)
05
Cooking pan
06
Fill tap
OPTIONAL
07
Lid
15
Shower
08
Lid handle
16
Plug socket
09
Mixer
17
Drain off valve
10
Mixer locking ring
18
Castors
10
09
15
06
08
05
07
18
02
16
11
01
04
03
17
12
13
14
