14
£
BurnerLogiX PROGRAMMER SELECTION
All programmers for the BurnerLogiX Series are designated with the prefix “YP”. The functional
operation, flame failure response time, purge timings, firing rate motor circuit, trial for ignition tim-
ings, recycling function and display messages are determined by the programmer.
A chart of the most common programmers is found below.
Take note of the programming sequence chart for each programming module for the proper explana-
tion of prepurge timings.
PTFI*MTFI TIMINGS
The BurnerLogix system provides keypad selectable timings for both PTFI and MTFI. The selections
offered can provide 5 or 10 second timing for terminal 5 and 6 or a shortened time for terminal 5,
allowing for early spark termination. BurnerLogix also provides selectable interrupted or intermittent
operation for terminal 6.
FIREYE
PART
NUMBER
Pre-purge
Programming
(Seconds)
Proven
High Fire
Interlock
(M-8)
Proven
Low Fire
Interlock
(M-D)
Terminal 6,
Interrupted
or
Intermittent
Early Spark
Termination
PTFI
(5/6)
MTFI
(5/6)
Running
Interlock
(3-P)
Flame Fail
Time
(Seconds)
Firing
Rate
Motor
SETTINGS SHOWN ARE FACTORY DEFAULT
YP100
30 YES YES INTRP NO 10/10 10/15 Non-recycle 4 YES
YP102
30 YES YES INTRP NO 10/10 10/15 Non-recycle 2 YES
YP138
30 YES YES INTRP NO 10/10 10/15 Non-recycle 4 YES
YP118
30 YES YES INTRP NO 10/10 10/15 Non-recycle 1 YES
YP113
30 YES YES INTRP NO 5/5 3/5 Non-recycle 1 YES
YP200
30 NO YES INTRP NO 10/10 10/15 Recycle 4 YES
YP202
30 NO YES INTRP NO 10/10 10/15 Recycle 2 YES
YP300
30 NO YES INTMT YES 10/10 10/
intmt
Recycle 4 NO
YP302
30 NO YES INTMT YES 10/10 10/
intmt
Recycle 2 NO
WARNING: THE INAPPROPRIATE SELECTION OR APPLICATION OF A PRO-
GRAMMER MODULE COULD RESULT IN AN UNSAFE CONDITION HAZARDOUS
TO LIFE AND PROPERTY. The various programmer modules are interchangeable
because they plug into a common YB chassis. Many parameters are configurable through
the keypad display. Care should be taken to insure the proper parameters are set. Refer to
the appropriate programmer bulletin for appropriate settings. Selection of the programmer
module and setting the various parameters for a particular application should be made by a
competent professional, such as a Boiler/Burner technician licensed by a state or govern-
ment agency, engineering personnel of the burner, boiler or furnace manufacturer (OEM)
or in the performance of duties based on the information from the OEM.
