Fireye YB110 User Manual

47
®
Table 7:
DEC HEX
BURNERLOGIX MESSAGES
1 1 H T16 M-D LIMIT OPEN - AUTO
2 2 H HOLD FALSE FLAME- STANDBY
3 3 R LOW FIRE PURGE
4 4 H HOLD M-8 LIMIT OPEN- PURGE
5 5 H See Interlock Annunciation Message Table
6 6 H T16 M-D LOW LIMIT - AUTO
7 7 L LOCKOUT FLAME FAIL - PTFI
8 8 H T16 INPUT CLOSED
9 9 H HOLD M-D LIMIT OPEN
10 A R IGNITION TIMING - PTFI
11 B C CHECK FLAME SIGNAL - MTFI
12 C R FLAME SIGNAL - AUTO
13 D R CYCLE COMPLETE - POST PURGE
14 E R L1-3 OPEN
15 F H T21 INPUT CLOSED
16 10 L LOCKOUT M-D LIMIT OPEN - PTFI
17 11 L LOCKOUT M-8 LIMIT OPEN
18 12 L LOCKOUT M-D LIMIT OPEN
19 13 L LOCKOUT FLAME FAIL - MTFI
20 14 L LOCKOUT FALSE FLAME
21 15 L LOCKOUT 3-P INTLK OPEN (PURGE)
22 16 L LOCKOUT 3-P INTLK CLOSED
23 17 H HOLD 3-P INTLK CLOSED - STANDBY
24 18 H HIGH FIRE PURGE
25 19 L LOCKOUT M-D LIMIT OPEN - MTFI
26 1A L LOCKOUT 3-P INTLK OPEN -AUTO
27 1B L LOCKOUT 3-P INTLK OPEN - MTFI
28 1C L LOCKOUT 3-P INTLK OPEN - PTFI
29 1D L LOCKOUT T13 FVES OPEN
30 1E L LOCKOUT 3-P INTLK OPEN - PREPURGE
31 1F C CHECK FLAME SIGNAL - PTFI
32 20 C CHECK M-8 HI LIMIT (HI FIRE PURGE)
33 21 C CHECK M-D LOW LIMIT (LO FIRE START)
34 22 R FLAME SIGNAL- PTFI
35 23 C-H HOLD T21 or CHECK LOW FIRE SIGNAL - AUTO
36 24 R FLAME SIGNAL - MTFI
37 25 L LOCKOUT FLAME FAIL (AUTO)
38 26 H HOLD 3-P INTLK OPEN - PREPURGE
39 27 L LOCKOUT FUEL VALVE STATE CHANGE
104 68 R LEARNING FLAME (PTFI and AUTO)
SYSTEM DIAGNOSTIC MESSAGES
54 36 L LOCKOUT CHECK CHASSIS
55 37 L LOCKOUT CHECK PROGRAMMER
56 38 L See Interlock Annunciation Message Table
57 39 L LOCKOUT CHECK EXPANSION MODULE
58 3A L LOCKOUT CHECK WIRING
