EXPLANATION OF LOGSTAT
LOGSTAT is an indication of what logic module the control is currently operating in during its cycle
and is used for diagnostic purposes only. If a lockout occurs the current value of LOGSTAT is stored
as part of the lockout information. The message displayed corresponds to the current logic module.
Table 6:
Logstat represents the current software module the BurnerLogix is currently executing.
The BurnerLogix outputs the current displayed message as well as the historical lockout messages as
numbers. The table below correlates the message number with the actual displayed text message.
LOGIC DISPATCHER
VALUE MODULE FUNCTION
DEC HEX
1 01H STANDBY Idle state
2 02H BLOWER ON 1/2 second period after operating control closes when blower motor is energized
3 03H PURGE Open Damper Purge or waiting for air flow and/or high fire switch to close
4 04H PURGE Low Fire Purge
5 05H PTFI Pilot Trial for Ignition
6 06H PTFI Pilot Trial for Ignition for YP3XX programmers
7 07H PTFI If PTFI is greater than 5 seconds and early spark termination is not needed
8 08H PTFI If PTFI is greater than 5 seconds and early spark termination is needed
9 09H PILOT Pilot Hold, YP138 only
10 0AH MTFI Main Trial for Ignition
11 0BH MTFI Main Trial for Ignition with terminal 5 de-energized
12 0CH AUTO Delayed valve on
13 0DH AUTO AUTO
14 0EH AUTO On YP138 programmer, hold for 20 seconds with terminals 6 and 7 energized
15 0FH AUTO On YP138 programmer, when terminal 21 first energized, wait for M-D to close
16 10H POSTPURGE Post Purge
17 11H POSTPURGE Post Purge period if flame fail lockout
18 12H POSTPURGE Idle state if unit is in lockout
