Fireye YB110 User Manual

49
®
R = RUN H = HOLD L = LOCKOUT C = CHECK
INTERLOCK ANNUNCIATOR
DEC HEX STATE TERMINAL YZ300 INTERLOCK ANNUNCIATOR LOCKOUT MESSAGES
41 29 L 3-43
HIGH WATER
42 2A L 43-44
LOW WATER
43 2B L 51-52
HIGH GAS PRESSURE
44 2C L 50-51
LOW GAS PRESSURE
92 5C L 52-54
AUX GAS
45 2D L 47-48
LOW OIL PRESSURE
56 38 L 44-46
HIGH OIL TEMPERATURE
46 2E L 46-47
LOW OIL TEMPERATURE
47 2F L 48-50
LOW ATOMIZING MEDIA
48 30 L 54-55
HIGH PRESSURE
49 31 L 55-56
HIGH TEMPERATURE
50 32 L 56-57
AUX #4 OPEN
51 33 L 57-58
AUX #5 OPEN
52 34 L 58-59
AUX #6 OPEN
53 35 L 59-60
AUX #7 OPEN
40 28 L 60-P
AIR FLOW OPEN
DEC HEX STATE TERMINAL YZ300 INTERLOCK ANNUNCIATOR HOLD MESSAGES
94 5E H L1-40
OP CONTROL OPEN
60 3C H 40-41
L1-3 AUX #1 OPEN
61 3D H 41-42
L1-3 AUX #2 OPEN
62 3E H 42-3
L1-3 AUX #3 OPEN
63 3F H-C 3-43
HIGH WATER
64 40 H-C 43-44
LOW WATER
65 41 H-C 51-52
HIGH GAS PRESSURE
66 42 H-C 50-51
LOW GAS PRESSURE
95 5F H-C 52-54
AUX GAS
67 43 H-C 47-48
LOW OIL PRESSURE
96 60 H-C 44-46
HIGH OIL TEMPERATURE
68 44 H-C 46-47
LOW OIL TEMPERATURE
69 45 H-C 48-50
LOW ATOMIZING MEDIA
70 46 H-C 54-55
HIGH PRESSURE
71 47 H-C 55-56
HIGH TEMPERATURE
72 48 H-C 56-57
AUX #4 OPEN
73 49 H-C 57-58
AUX #5 OPEN
74 4A H-C 58-58
AUX #6 OPEN
75 4B H-C 59-60
AUX #7 OPEN
5 5 H-C 60-P
AIR FLOW OPEN
