2
£
Wiring bases for the BurnerLogix control are available pre-wired with 4 foot lead wires color coded
and marked for easy installation or with an integral terminal block capable of a accepting up to 2 X
14 AWG wires. The wiring base terminal block is available with knockouts for conduit or open
ended for cabinet mounting. The pigtail wiring base is 4" X 5" and the terminal block wiring base is
4" X 7".
Additional functions of the BurnerLogix system include:
• A non-volatile memory which allows the control to remember its history and present position
even when power is interrupted.
• A consistent flame signal read-out via display module or 4-20 mA output.
• Read-out of main fuel operational hours and complete cycles via display module.
• Modbus communications via RS485 multi-drop link.
• Proof of fuel valve closure during off cycle.
• Burn-in time of program parameters occurs after 8 hours of main valve on time.
• A run/check switch which allows the operator to stop the program sequence in any of four
different positions (Purge, PTFI, MTFI or Auto).
• Remote Display mounting with NEMA 4 protection.
• Remote Reset.
• Programmable communication baud rate allows for DCS compatibility.
• Keypad selectable language readout.
• Revert to pilot can increase burner turn down.
• Additional terminals provided for applications requiring additional inputs and outputs.
WARNING: This equipment is a Class B digital apparatus which complies with the Radio
Interference Regulations, CRC c.1374.
CAUTION: While programmers are mechanically interchangeable in that they mate with a
common chassis/amplifier module, you should select the correct model for your application.
Inappropriate application of a control could result in an unsafe condition hazardous to life
and property. Selection of a control for a particular application should be made by a compe-
tent professional, such as a boiler/burner service technician licensed by a state or other gov-
ernment agency.
