BurnerLogix Displays
BLV512
Display, 2 line X 16 characters, VFD, with cable, NEMA 4
BLL510
Display, 2 line X 16 characters, LCD, with cable, NEMA 4
BurnerLogix wiring bases
60-2810-1
Pigtail wires, 4 foot long, 4"W x 5"H
60-2812-1
Closed base with terminal block and knockouts, 4"W x 7"H
60-2814-1
Open base with terminal block. 4"W x 7"H
BurnerLogix Accessories
129-178-4
Kit, remote mounting, BurnerLogix display, 4 ft. cable, provides NEMA 4 protection
129-178-8
Kit, remote mounting, BurnerLogix display, 8 ft. cable, provides NEMA 4 protection
BLD500
Blank display module, included with YB module
IT1000
Alarm annunciation system using wireless technology
PPC6000
Parallel Positioning System
61-5745-3
Shutter drive assembly for redundant self-check scanners
SCANNER SELECTION
FIREYE P/N DESCRIPTION USE WITH CHASSIS BULLETIN
48PT2-1003
48PT2-9003
48PT2-1007
48PT2-9007
4-263-1
Infrared 1/2" straight mount 96"(2438mm) flex conduit
Infrared 1/2" straight mount 96" (2438mm) flex conduit
Infrared 1/2" straight mount 48" (1219mm) flex conduit
Infrared 1/2" 90° angle mount 48" (1219mm) flex conduit
Replacement photo detector
YB110IR
YB230IR SC-103
UV1A3
UV1A6
UV8A
UV2
UV2A6
45UV3-1050
UV90-3
UV90-6
UV90-9
UV 1/2" straight 36" (915mm) flex conduit
UV 1/2" straight 72" (1830mm) flex conduit
UV 1/2" 90° head 72" (1830mm) flex conduit
UV 3/8" straight 36"(915mm) flex conduit
UV 3/8" straight 72" (1830mm) flex conduit
UV 3/4" cast aluminum housing 96" (2438mm) unshielded leads
UV 90° lateral view with 36" (915mm) flex conduit
UV 90° lateral view with 72" (1830mm) flex conduit
UV 90° lateral view with 108" (2745mm) flex conduit
YB110UV
YB230UV
SC-102
45UV5-1007
45UV5-1009
4-314-1
Self-check UV 1" BSP threads, 102-264VAC
Self-check UV 1" NPT threads, 102-264VAC
Replacement UV tube
YB110UVSC
YB230UVSC
SC-101
45UV5-1005
45UV5-1105
Self-check UV 1" NPT threads, 61-5745-3 required
Self-check UV 1" BSP threads, 61-5745-3 required
YB110UVSC
YB230UVSC
133-645
55UV5-1007
55UV5-1009
Self-check UV 1" BSP, 102-264VAC, Suitable for hazardous locations.
Self-check UV 1" NPT, 102-264VAC, Suitable for hazardous locations.
YB110UVSC
YB230UVSC
SC-106
