Caution If tipped more than 45°, allow the unit to set upright for 24 hours
before start up.
s
To remove the freezer from the pallet, use the 7/16" wrench to remove all
the bolts securing the shipping bracket to the pallet.
Remove the shipping bracket. Remove the ramp boards from the pallet and
place the slotted end over the ramp brackets on the pallet. The support
blocks on the ramps will be facing down. Before moving the freezer, make
sure the casters are unlocked and moving freely. Align the caster with the
ramp boards. Use adequate personnel to roll the freezer off the pallet.
The freezer can be easily pushed to the desired approved location,
described in the following section. If necessary, the doors and lower front
panel may be opened to move the unit through tight openings. When the
freezer is in position, set the front caster brakes.
Caution The freezer must not be moved with the product load inside.
s
Caution For proper ventilation and airflow, minimum clearance of 5” at
the rear and top and clearance of 8” on the side of the freezer is required.
Allow adequate space on freezer front for door opening.
s
Locate the freezer on a firm, level surface in an area with an ambient
temperature between 18°C and 32°C. Provide ample room to reach the
mains disconnect switch (power switch) located on the rear of the freezer.
The parts bag, located inside the cabinet, contains the following parts.
Install the bolts into the pre-tapped holes on the back of the compressor
section. Install a neoprene cap on each bolt. Refer to Figure 1-2 for the
locations of the pre-tapped holes.
1-4 Isotemp Basic Fisher Scientific
Section 1
Installation and Start-Up
Install Freezer
Choose the Location
Install the Wall Bumpers
Quantity Stock # Description Purpose
2 510016 1/4-20 x 5-1/2” Bolt Wall Bumper
2 380520 Neoprene Cap Cap Protector
