Fisher Scientific Isotemp Basic -86C - Section 1 Installation and Start-Up

Figure 1-1
• Control Panel - keypad,
displays and indicators.
• BUS (Optional Back Up
System) panel.
• Optional temperature
recorder - 7 day, one pen
or Datalogger.
• Vacuum relief port cover
plate
Figure 1-2
• Remote alarm contacts.
• Power Inlet for power cord connection.
• Optional BUS connections for probe and solenoid.
• Power Switch (mains disconnect).
Isotemp Basic 1-1Fisher Scientific
Section 1 Installation and Start-Up
Figure 1-1. Front View
Optional Back-up
System Connections
Power Switch
(mains
disconnect)
Power Inlet
Remote Alarm
Contacts
Wall Bumper
(pre-tapped holes)
Figure 1-2. Rear View
