Preface
Isotemp Basic i
MANUAL NUMBER 7028953
1 30775/30673/FR-2607 2/4/14 Intended use and battery check - pgs ii & 4-5 ccs
0 30643 12/17/13 Release 9 - Oil and breaker - refrigeration schematics ccs
REV ECR/ECN DATE DESCRIPTION By
Catalog
Number
Model
Capacity
(cu. ft.)
Voltage
IE1386V 8953 13 230/50
IE1386D 8954 13 230/60
IE1386A 8955 13 120/60
IE1786A 8956 17 120/60
IE1786D 8957 17 230/60
IE1786V 8958 17 230/50
IE2386V 8959 23 230/50
IE2386D 8963 23 230/60
IE2386A 8964 23 120/60
Packing List
Part Number Description Quantity
122005 Key 2
380520 Neoprene Cap 2
510016 1/4-20 x 5-1/2” Bolt 2
195763 Retaining Clip 1
370563 Remote Alarm Connector 1
Important installer and user information:
A redundant temperature sensing device has been included in this ULT
freezer. This device is a type “T” thermocouple. For convenient access,
the thermocouple (Figure 1-3) terminates in an interconnect jack (Figure
1-5) behind the base front cover. (May be located differently in chests.
See Section 1.) It is strongly recommended that this thermocouple be
attached to a redundant 24 hour 7 day monitoring system with alarm
capabilities. Connecting the sensor to a monitoring and alarm system
separate from the freezer provides the utmost in product safety, should
the integral system fail.
