Fisher Vee-Ball V150 - Valve Description; Valve Specifications; Educational Services for Valve Training

Instruction Manual
D101554X012
Vee-Ball Valves
June 2017
2
Table 1. Specifications
Valve Sizes
See table 2
Valve End Connection Styles
V150: Flanged valves that mate with CL150
raised-face flanges and EN 1092-1 Type B raised-face
and Type F Recess
V200: Flangeless (all sizes) and flanged valves that
mate with CL600 raised-face flanges (NPS 2-8)
V300: Flanged valves that mate with CL300
raised-face flanges and EN 1092-1 Type B raised-face
and Type F Recess
Maximum Inlet Pressure
(1)
Consistent with applicable ASME B16.34 or
EN 12516-1 ratings
Standard Flow Direction
Forward (into the convex face of the Vee‐ball)
Actuator Mounting
J Right‐hand, standard or J left‐hand, optional, as
viewed from upstream end of valve (see figure 23 and
the Actuator Mounting section)
Maximum Ball Rotation
Standard: Ball rotates counterclockwise to close
when viewed from actuator side of valve
Optional: Ball rotates clockwise to close
Ball rotation is 90 degrees
Valve/Actuator Action
With diaphragm or piston rotary actuator,
field‐reversible between:J push‐down‐to‐close
(extending actuator rod closes valve) and
J push‐down‐to‐open (extending actuator rod
opens valve.) See actuator manual for details
1. The pressure/temperature limits in this manual, and any applicable code or standard limitation, should not be exceeded.
Description
The V150, V200, and V300 Vee‐Ball valves (figure 1) with a V‐notch ball are used in throttling or on‐off service. The
V200 is a flangeless construction. The V150 and V300 valves are raised‐face flanged constructions. The splined valve
shaft of all these valves connect to a variety of rotary‐shaft actuators.
Specifications
Specifications for these valves are shown in table 1 and in the Fisher Vee-Ball V150, V200, and V300 Rotary Control
Valves Bulletin 51.3:Vee‐Ball (D101363X012
).
Educational Services
For information on available courses for Fisher Vee-Ball valves, as well as a variety of other products, contact:
Emerson Automation Solutions
Educational Services - Registration
Phone: 1-641-754-3771 or 1-800-338-8158
E-mail: education@emerson.com
emerson.com/fishervalvetraining
