INSTRUCTION MANUAL FIT REMOTE DISPLAY PINION
8 ERROR MESSAGES
8.1 GENERAL INFORMATION
The parts of the e-bike system are permanently monitored during use and charging. The error code is shown on the
display when an error is detected. Press on the rocker switch to acknowledge the error and switch back to the default
screen on the display. If the error cannot be acknowledged, use the table in section 8.3.1 to eliminate it or contact
your specialist dealer. Power assistance is automatically stopped where necessary depending on the specific error
code. You can still use the e-bike conventionally as a normal bicycle even if the motor no longer provides assistance.
An error can be clearly categorised with the displayed category and the displayed code. A text which indicates the
error category is also always displayed.
8.2 STATUS LED ON OPERATING ELEMENT AND DISPLAY
The operating element and the display each feature a status LED to indicate error statuses. The operating element’s
LED is located in the rocker switch. It is in the top left-hand corner in Display Compact and in the top right-hand corner
in Display Comfort.
The statuses are listed in the following table:
Colour Flash sequence Status
Green Continuously lit System must be connected to the maintenance tool at the
specialist dealer’s.
Red Continuously lit Re-start the system if the status LED still lights up red. Have
component replaced at the specialist dealer’s.
Red Flashing Re-start the system if the status LED still flashes red. Have
component replaced at the specialist dealer’s.
8.3 INFORMATION / ERROR DISPLAY
There are four different types of error messages:
Type Display Effect
Information White circle with black i Motor assistance available
The message can be acknowledged by pressing the
selection rocker switch.
Warning White triangle with black
exclamation mark
Motor assistance available
The message can be acknowledged by pressing the
selection rocker switch.
Error Orange bar No motor assistance
Motor assistance is only available once the error
has been rectified.
Critical error Orange bar and the rocker switch
lights up red
No motor assistance
Motor assistance is only available once the error has
been rectified and the system has been restarted.
FIT_Manual_Remote_Display_Pinion_V3_en | Version 03 | 24.10.2023 32
