1. Overview of the Instrument
2. Technical Indicators
The instrument shall specify the period of one year, and needs to be recalibrated under
the conditions of 18 ℃ (64.4℉) ~ 28 ℃ (82.4℉) and relative humidity less than 75%.
Automatic Measurement and Manual Measurement
Overload Protection
The Maximum Voltage Allowed between the Measuring Terminal and Earth: 1000V DC or
750V AC
Working Height: Maximum 2000m
Environment Temperature: 23±5℃ (73.4±41℉）
Relative Humidity: <75%
Display: LCD
Maximum Display Value: 5999
Polar Indication: Automatic indicator, '-' indicates negative polarity
Over Range Display: ‘0L’ or ‘-0L’
Sampling Time: about 3 times / sec
Display Unit: function / power
Auto Shutdown: 15 Minutes
Power: DC current 4.5V
Battery: 1.5V AAA
Battery Under-voltage Indication:
Temperature Coefficient: lower than 0.1 × Accuracy / ℃
Operating Temperature: 18 ℃ (64.4℉）～ 28 ℃（82.4℉）
Storage Temperature: -10℃ (14℉）～ 50℃ (122℉）
The maximum size of jaw opening: about 36mm (1.4 inches)
The maximum wire diameter that can be measured by the jaw: about 26mm (1 inch)
Size: 208 × 78 × 35mm（8.2×3.1×1.2 inches）
Weight: about 240g (8.5 oz)（Including battery）
