18. Temperature Measurement
Warning
In the temperature measurement range, do not input a voltage higher than
DC 60V or AC 30V to avoid injury or damage caused by the instrument.
Turn the function rotary switch to the temperature measurement position (select ℃ or
℉ as needed).
Connect the negative and positive ends of the K-type thermocouple to the COM termi-
nal and INPUT terminal.
Place the other end of the K-type thermocouple in the measured object or environ-
ment.
Read the value of the measured temperature on the LCD display.
In order to improve the accuracy of the measured value below 10nF, the distributed
capacitance of the meter and wire should be subtracted.
Range
-50℃－300℃
301℃－1000℃
-58℉－600℉
601℉－1832℉
Resolution Accuracy
1℃
1℃
1℉
1℉
±(1.0% + 4d)
±(1.9% + 5d)
±(1.2% + 6d)
±(1.9% + 6d)
Notice:
