16. Continuity Test
17. Capacitance Measurement
Warning
The risk of electric shock.
When measuring the impedance on the circuit, make sure that the power
supply of the circuit is disconnected and the capacitor on the circuit is
completely discharged.
Warning
The risk of electric shock.
To avoid electric shock, the capacitor should be completely discharged
before measuring the capacitance.
Insert the black test leads into the COM terminal and the red test leads into the INPUT
terminal.
Set the rotary switch to the position.
Press the “SEL” key to switch to continuity test state.
Connect the test leads to both ends of the circuit for measurement.
If the resistance of the tested circuit is lower than 50Ω, the internal buzzer may sound.
Read the resistance value on the LCD display.
If the test leads are in open circuit or the resistance of the tested circuit is greater than 600
Ω, the display will show “0L”.
Insert the black test leads into the COM terminal and the red test leads into the INPUT
terminal.
Set the rotary switch to the position.
Press the “SEL”key to switch to the capacitor test status.
After the capacitor is fully discharged, connect the test leads to both ends of the mea-
sured capacitor for measurement.
Read the capacitance value on the LCD display.
