Use the instrument as described in the manual and within the correct ranges.
During measurement, do not exceed the indicated value of the protection range of
each test.
When measuring circuit, do not touch the test leads tip (the metal part).
During the measurement, if the measured voltage is higher than 60V DC or 30V AC
(RMS), keep fingers behind the finger guards at all times.
Do not attempt to measure any voltage that might exceed AC 750V between the mea-
suring terminal and the ground.
Before turning the rotary switch to change the measurement function, the test leads
should be removed from the circuit under test.
Do not measure resistance, capacitance, diode and circuit continuity when the circuit
is connected.
Under the test of current, resistance, capacitance, diode and continuity, beware to
avoid connecting the meter to the power source.
Do not measure the capacitance before the capacitor is fully discharged.
Do not operate the instrument around explosive gas, vapor, or dust.
If there is any abnormality or malfunction of the instrument, stop using it immediately.
The instrument should not be used unless the bottom shell and the battery cover are
fully fastened in place.
Do not store or use the instrument in direct sunlight, high temperature or high humid-
ity conditions.
2. Safety Instructions
3. Icon Explanation
CAT III
Important information
Can be used for dangerous live conductor
Double insulated
In line with FCC certification
Ground
In accordance with the IEC-61010-1 over-voltage
standard (installation) level III. The pollution degree 2
refers to the pulse voltage protection levels.
