2.4 AC Voltage
2.5 Frequency
2.5.1 Through the V file:
In the small voltage range, if the test leads are not connected to the circuit under test, the
meter may have a pulsating reading. This is normal. This is caused by the high sensitivity
of the meter and does not affect the actual measurement result.
- Range: 10 ~ 10kHz
- Input Voltage Range: ≥ 2V AC (Effective value) (With the increase of the measured
frequency, the input voltage should be increased accordingly.)
- Input Impedance: 10MΩ
- Maximum Input Voltage: 600V AC (Effective value)
- Frequency: 10 ~ 1kHz
- Input Current Range: ≥ 20A AC (Effective value)
- Input Max Current: AC 6000A
Range
6V
60V
600V
Resolution Accuracy
±(1.0% + 5）
±(1.2% + 5）
0.001V
0.01V
0.1V
Range
99.99Hz
999.9Hz
9.999kHz
Resolution Accuracy
±(0.5% + 5）
0.01Hz
0.1Hz
0.001kHz
- Input Impedance: 10MΩ
- Maximum Input Voltage: 600V AC（Effective value）or 600V DC
- Frequency Range: 40 ~ 1000Hz
2.5.2 Through A File (From Clamp):
Notice:
