PowerFLARM Manual Version 1.0
Audio
To make sure that an acoustic warning can be heard above loud
ambient noise, the signal may be fed direct into the intercom or
headset. To this end, there is a 3.5 mm socket for a jack plug on
the rear side of the unit.
PowerFLARM also has an integral warning bleeper. The housing
front face has an outlet to improve sound release from the
internal bleeper. This outlet must not be obstructed by any
adhesive agent.
When set at large volume, the bleeper sound level
could damage a human ear at close distance. The
volume is adjustable.
Micro SD-Card
FLARM has a built-in microSD card reader. The microSD card
(also known as TransFlash) is not supplied, but is in widespread
use for mobile telephones and can be purchased from most
camera or mobile phone retailers. FLARM uses the microSD card
to update the firmware, obstacle and terrain data, to configure
the unit and download the flight log.
Some functions are not available in all
PowerFLARM versions; these may be available for
payment of an additional charge or fee.
microSD cards are smaller than SD cards or miniSD cards.
However, for communication with a PC there are mechanical
adapters for insertion of a microSD card in SD or a miniSD card.
Such adapters are often sold together with the cards.
Note, that the microSD card must be formatted to FAT or FAT32.
Insertion and Removal
Hold the card with the metal contacts on the right and insert
carefully into the slot; then, gently press with the fingertip until
the card is retained with a slight 'click'. To remove the card,
press the card gently into the FLARM slot until a slight click
To Next Page
