6. Click [Print] and the machine starts printing
the built-in file (configured for PLA material).
5. Please clear the filament residues on the nozzle
and platform. Users must apply glue to the
platform so as to improve adhesion for the
first print.
C3. Feeding will begin after heating. Successful filament extrusion from the nozzle indicates
successful loading. Lastly, confirm the filament guide tube is properly inserted.
If no filament is extruded, manually insert the filament into the inlet and click
[Back] to retry. Feel for filament movement until it is extruded.
Note
13
