11
TRANSMITTER SETUP
WARNING
DO NOT ATTEMPT RADIO SETUP WITH PROPELLER INSTALLED. INADVERTENT POWER UP COULD CAUSE PERSONAL INJURY.
TRANSMITTER SETUP GUIDE
End Points*
Aileron/Elevator/Rudder
Throle
125%
100%
Sub Trim
Veried at zero, sub-trim not allowed
Trim Levers
Veried at zero
CH. 5 (Gear)
Assigned to a 3-posion switch
CH. 6 (AUX1)
Assigned to a 3-posion switch OR Flap System
If using ap system, assign 100%, 0%, -100%
Begin by starng with a freshly reset and new model memory in your transmier. Make ONLY the changes shown in the Transmier Setup Guide.
The Aura 8 on the Cessna 170 defaults to 3 ight modes that are switched via CH5/Gear in your transmier. You may need to reassign CH5/Gear to
a 3-posion switch. Consult your radio manual for direcons on channel assignment.
Reversing
Ail/Ele/Rudder set to Normal
Thro/Flap depends on transmier manufacturer
Timer
Set to 4:00 for inial ights
Descripon of Pre-Loaded Aura Flight Modes (FM)
FM 1:
FM 2:
FM 3:
Flight Control system is o. Rates are set for general ight
(same as FM 2). Exponenal is tuned for comfortable ight.
Rudder to aileron and rudder to elevator mix acve.
Flight Control system is on. Gains are moderate and tuned
for comfortable feel/best performance. Rates are set for
general sport ying, and expo is tuned for comfortable
ight. Rudder to aileron and rudder to elevator mix acve.
Flight Control system is on. Gains are moderate and tuned
for comfortable feel/best performance. Rates are set for
aggressive ying, and expo is tuned for comfortable ight.
Rudder to aileron and rudder to elevator mix acve.
Note: Rudder sck movement will also move ailerons and elevator.
This funconality is NORMAL.
Each of the modes has been tuned by our team to oer a solid start.
Because tastes in control feel are unique, if changes in rates and
expo are needed, adjustments should be made through the Aura 8.
Changes in gain value can only be made via Master Gain, or through
the Aura Cong Tool (Windows Applicaon).
AURA FLIGHT MODE REFERENCE
Aura 8
Rate Setup
Aileron
Elevator
Rudder
Mode 1 Mode 2 Mode 3
Aileron
Elevator
Rudder
Aura 8
Expo Setup
Mode 1
Mode 2
Mode 3
70% 100%
45% 45% 100%
100% 100% 100%
30% 10% 15%
30% 15% 40%
40% 35% 35%
CONNECTING BATTERY/ARMING ESC
Observe the following procedures to safely power up your model aer
it has been bound. Ensure propeller is removed unless sequence is
followed to power up before ight.
1.
2.
3.
4.
Lower the throle sck and trim to their lowest seng and turn
on the transmier. Wait for your transmier to indicate the RF
signal is being broadcast before proceeding.
If a baery is connected to the ESC with the throle fully open
on the acve transmier, the ESC will enter into programming
mode. If this occurs, simply disconnect the baery, lower the
throle, and reconnect the baery.
Ensure the rudder, elevator and aileron scks are centered.
With the airplane on a solid surface, connect the baery to the
ESC and wait. The ESC will emit a series of audible tones during its
inializaon process.
The ESC will emit a short, nal tone sequence indicang that the
ESC is now armed, and that the motor will spin in response to
throle sck movement.
When making adjustments to linkages, transmier sengs, or the
Aura 8 ight control system, REMOVE THE PROPELLER to guard
against accidental spool up.
WARNING
Hold aircra securely when connecng the ight baery before
ight. Always ensure that the propeller is clear of any and all
objects, as they may become entangled.
CAUTION
Always connect the baery when the throle and
throle trim are in the cut-o posion.
70%
*Note: JR Mode B Users set Throle, Aileron, Elevator, Rudder and Gear Travels to 88%
Note: These are for reference only. DO NOT put these values into your transmier.
WARNING
For large (greater than 5%) changes in expo, or dual rates, it is highly
recommended to reset all expos and rates to default in the transmier,
and tune through the Aura Cong Tool.
The Aura Cong Tool can be used on any Windows-based PC or Tablet,
and can be downloaded at the following address:
www.exinnovaons.com/arcles.asp?ID=257
