FLIGHT CONTROLLER SENSOR DIRECTION TEST
Perform a test of the gyro system to verify the correcons made for a given movement are correct. If any of the tests do not result in the correct
reacon from the airplane's gyro system, do not y the airplane, and contact us via email at support@exinnovaons.com
The ight control system acvates with RF broadcast. Perform thest tests in Flight Mode 3 (highest gain) for beer visibility and then in Flight Mode
2, and any other modes that have gyro gains assigned. (By default, Mode 1 has no gain assigned). Control surface deecons are exaggerated in the
drawings below for clarity. Note that the control surfaces will only deect while the model is rotang.
Aircra
Movement
Proper Control
Surface Deecon
AILERON
ELEVATOR
RUDDER
15
