7 Connection FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 83
7.6 Serial Interface
7.6.1 RS232 Interface
The RS232 interface is located on the front plate of the transmitter (see Fig. 7.45, Fig. 7.46 or Fig. 7.47).
• Connect the RS232 cable to the transmitter and to the serial interface of the PC. If the RS232 cable cannot be connected
to the PC, use the RS232/USB adapter.
The RS232 cable and the RS232/USB adapter are part of the serial data kit (optional).
7.6.2 RS485 Interface
The transmitter can also be equipped with an RS485 interface (optional).
FLUXUS F704, F705, F706
For the connection of the RS485 cable to the transmitter, see box Cable connection S. 75, Fig. 7.1 or Fig. 7.2, Fig. 7.45 or
Fig. 7.46 and Tab. 7.19)
.
Attention! Observe the "Safety Instructions for the Use in Explosive Atmosphere" (see document SIFLUXUS).
Note! If a problem occurs when the RS232/USB adapter is used for the connection, contact your system
administrator.
Fig. 7.45: Transmitter FLUXUS F704
Fig. 7.46: Transmitter FLUXUS F705, F706
(example with FLUXUS F705)
Fig. 7.47: Transmitter FLUXUS F709
AVSAV
AGN
ARS
AR
BVSBV
BGN
BRS
BR
SA1
SA2
SA3
SA4
SB1
SB2
SB3
SB4
T1a
T1b
S2 T2a
T3a
T3b
S4
T4a
T2b
T4b
T1A
T1B
S1 T2A
T3A
T3B
S3
T4A
T2B
T4B
A+
B-
P1+ P2+
P4+
P5a
P6a P7a
P3+
101
103
P1- P2-
P4-
P5b
P6b
P7b
P3-
PE
N(-)
L(+)
cable gland
cap nut
compression part basic part
serial interface
RS485 (optional)
serial interface
RS232
AVS
AV
AGN
ARS
X2
X_BV
X_BR
X_AV
X_AR
X1
AR
BVS
BV
BGN BRS
BR
SA1 SA2 SA3 SA4 SB1
SB2
SB3
SB4
T1a T1b
S2 T2a
T3a
T3b
S4
T4a
T2b
T4b
T1A T1B
S1 T2A
T3A
T3B
S3
T4A
T2B
T4B
A+
B-
P1+ P2+
P4+
P5a
P6a P7a
P3+
101
103
P1- P2-
P4-
P5b
P6b
P7b
P3-
PE
N(-)
L(+)
cap nut
compression
part
basic part
ferrite nut
cable gland
sealing ring:
only for cable gland M20,
not for cable gland 1/2 NPS
serial
interface
RS232
serial interface
RS485 (optional)
