9 Basic Measurement FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 91
9 Basic Measurement
The pipe and medium parameters are entered for the selected measuring point (see chapter 5). The parameter ranges are
limited by the technical characteristics of the transducers and of the transmitter.
9.1 Input of the Pipe Parameters
9.1.1 Outer Pipe Diameter/Pipe Circumference
It is possible to enter the pipe circumference instead of the outer pipe diameter (see section 14.2.1).
If the input of the pipe circumference has been activated and 0 (zero) is entered for the Outer Diameter, the menu item
Pipe Circumfer. will be displayed. If the pipe circumference is not to be entered, press key BRK to return to the main
menu and start the parameter input again.
9.1.2 Pipe Wall Thickness
Attention! Observe the Safety Instructions for the Use in Explosive Atmosphere (see document SIFLUXUS).
Note! During the parameter input, the transducers have to be connected to the transmitter.
Note! The parameters will only be stored when the program branch Parameter has been edited in its en-
tirety.
Select the program branch Parameter. Press ENTER.
Select the channel for which the parameters are to be entered. Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
Enter the outer pipe diameter. Press ENTER.
An error message will be displayed if the entered parameter is outside of the range. The
limit will be displayed.
Example: upper limit 1100 mm for the connected transducers and for a pipe wall thickness
of 50 mm.
Enter the pipe wall thickness. Press ENTER.
Note! The inner pipe diameter (= outer pipe diameter - 2x pipe wall thickness) is calculated internally. If the
value is not within the inner pipe diameter range of the connected transducers, an error message will
be displayed.
It is possible to change the lower limit of the inner pipe diameter for a given transducer type (see sec-
tion 11.9).
Parameter ↕
for Channel A:
Outer Diameter
1100.0 MAXIMAL
