FlexRadio Systems FLEX-5000A User Manual

O P E R A T I O N C H A P T E R 6
1. Follow the Power Up Procedure, described on page 156. Then click the Start/Stop button
(14). Set the following controls as specified in Table 11 below.
Table 11: Initial Control Values for Voice Operation
Ctrl Value
Reference to
Figure 148
VFO A 14.3MHz (1)
RX1 Meter Signal (4)
TX Meter MIC (4)
BAND 20 (5)
Mode USB (6)
Filter 2.7kHz (7)
Mic Gain 35 (8)
DX Off (8)
CPDR Off (8)
VOX Off (8)
GATE Off (8)
RX EQ Off (8)
TX EQ Off (8)
VAC Off (8)
Display Mode Panadapter (9)
AVG On (9)
PEAK Off (9)
MultiRX Off (10)
SPLT Off (12)
XIT Off (12)
RIT Off (12)
MUT Off (17)
ATU/BYP ATU (if applicable) (20)
AF 50 (21)
AGC-T 70 (22)
Drive 50 (23)
AGC Med (24)
Preamp On (25)
SQL Off (26)
RX2 Off (if applicable) (29)
2. In the Antenna Form (38) choose Simple complexity level and set RX1 to ANT1 (see page
149 for more on the Antenna Form). Connect a 50 ohm dummy load to the ANT 1 antenna
jack, or tune VFO A (1) to a quiet frequency on the selected band. Use the TUN (19) button
to verify power output on the TX Meter (4) (Set to Fwd Pwr). If using the optional,
integrated ATU, select Automatic on the ATU Form (39) and then click the TUN (19)
button. See the section on the ATU Form on page 153 for more on how to use the ATU.
