7 Status/error indications
In case of disturbance or malfunction the indicator will show various
status/error indications. For weighing faults such as overload, signal out
of range or sense errors etc. the indicator has special dedicated
indications, for other operational errors the indicator has a general error
code indication.
For a more complete description of the error codes consult the 4-55424
Weight indicator 47-11 Instruction manual.
7.1 Weighing faults indications
Weighing faults are errors that will impede the indicators ability to
operate normally, i.e. critical faults.
In general, any weighing fault, such as overload, signal out of range,
sense missing etc. will be signalled as ‘overload’ (weight not valid) on
communications protocols.
During weighing faults, no weighing functions are available.
A load over Scale Maximum Capacity + 9.5 scale intervals, or no scale
connected is displayed as:
Corrective actions:
• Remove load from scale platform
• Check wiring/connection to the scale
