2 Installation
If the weight indicator is supplied as part of a complete scale, then it is
usually calibrated and setup in accordance with the order specification.
Installation in this case only require the connection of peripheral
equipment as per schematics below:
Peripheral
or
Y
Serial :1
Serial:2
Ethernet
Display
kg
Power
Scale
