Operation
7
7.5 Deleting an image
7.5.1 General
You can delete one or more images from the internal camera memory.
7.5.2 Procedure
Follow this procedure:
1. Push the Archive button
.
2. Push the navigation pad left/right or up/down to select the image you want to view.
3. Push the center of the navigation pad. This displays the selected image.
4. Push the center of the navigation pad. This displays a toolbar.
5. On the toolbar, select Delete
.
7.6 Deleting all images
7.6.1 General
You can delete all images from the internal camera memory.
7.6.2 Procedure
Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Settings
. This displays a dialog box.
3. In the dialog box, select Device settings. This displays a dialog box.
4. In the dialog box, select Reset options. This displays a dialog box.
5. In the dialog box, select Delete all saved images.
7.7 Measuring a temperature using a
spotmeter
7.7.1 General
You can measure a temperature using a spotmeter. This will display the temperature at
the position of the spotmeter on the screen.
7.7.2 Procedure
Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Measurement
. This displays a toolbar.
3. On the toolbar, select Center spot
.
The temperature at the position of the spotmeter will now be displayed in the top left
corner of the screen.
7.8 Measuring the hottest temperature within
an area
7.8.1 General
You can measure the hottest temperature within an area. This displays a moving spot-
meter that indicates the hottest temperature.
#T559828; r. AP/56791/57153; en-US
14
