Operation

7.20 Changing the distance between the object

and the camera

7.20.1 General

To measure temperatures accurately, the camera requires the distance between the

camera and the object.

7.20.2 Procedure

Follow this procedure:

1. Push the center of the navigation pad. This displays a toolbar.

2. On the toolbar, select Settings

. This displays a dialog box.

3. In the dialog box, select Measurement parameters. This displays a dialog box.

4. In the dialog box, select Distance. This displays a dialog box where you can select a

distance.

7.21 Performing a non-uniformity correction

(NUC)

7.21.1 What is a non-uniformity correction?

A non-uniformity correction is an image correction carried out by the camera software to

compensate for different sensitivities of detector elements and other optical and geomet-

rical disturbances

7.21.2 When to perform a non-uniformity correction?

The non-uniformity correction process should be carried out whenever the output image

becomes spatially noisy. The output can become spatially noisy when the ambient tem-

perature changes (such as from day to night operation, and vice versa).

7.21.3 Procedure

To perform a non-uniformity correction, push and hold the Image archive button

for

more than 2 seconds.

7.22 Configuring Wi-Fi

Depending on your camera configuration, you can connect the camera to a wireless local

area network (WLAN) using Wi-Fi, or let the camera provide Wi-Fi access to another

device.

You can connect the camera in two different ways:

• Most common use: Setting up a peer-to-peer connection (also called an ad hoc or

P2P connection). This method is primarily used with other devices, e.g., an iPhone or

iPad.

• Less common use: Connecting the camera to a WLAN.

7.22.1 Setting up a peer-to-peer connection (most common use)

Follow this procedure:

1. Push the center of the navigation pad. This displays a toolbar.

2. On the toolbar, select Settings

. This displays a dialog box.

3. Select Device settings and push the center of the navigation pad.

#T559828; r. AP/56791/57153; en-US

1. Definition from the impending international adoption of DIN 54190-3 (Non-destructive testing – Thermographic

testing – Part 3: Terms and definitions).

Need help?

Do you have a question about the FLIR E6-XT and is the answer not in the manual?

FLIR E6-XT Specifications

General

Accuracy	±2°C or ±2% of reading
Field of View	45° × 34°
Weight	0.575 kg (1.27 lb)
Image Frequency	9 Hz
Dimensions	244 × 95 × 140 mm (9.6 × 3.7 × 5.5 in)
Spectral Range	7.5 – 13 µm
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Water and Dust Resistance	IP54
Resolution	240 × 180 pixels
Thermal Sensitivity	<0.06°C
Temperature Range	-20°C to +550°C
Display	3.0 in 320 × 240 color LCD
Image Modes	Thermal, MSX, Picture-in-Picture
Battery Life	4 hours
Digital Camera	640 x 480 pixels
File Format	Radiometric JPEG
Battery Type	Rechargeable Li-ion battery
Connectivity	Wi-Fi, USB
