427-0030-00-12 Version 180 March 2018 14
1 F-Series Camera Installation
1.8 F-Series Camera Specifications
Thermal
Camera
Specifications
Array Format (NTSC) 320 × 240 640 × 480
Detector Type Long-Life, Uncooled VOx Microbolometer
Effective Resolution 76,800 307,200
Pixel Pitch 25 µm 17 µm
Thermal Frame Rate NTSC: 30 Hz or 7.5 Hz or PAL: 25 Hz or 8.33 Hz
Optical
Characteristics
Model FOV
Focal
Length
Model FOV
Focal
Length
F-348 48° × 39° 9 mm F-645 45° × 37° 13 mm
F-334 34° × 28° 13 mm F-625 25° × 20° 25 mm
F-324 24° × 19° 19 mm F-618 18° × 14° 35 mm
F-313 13° × 10° 35 mm F-612 12° × 10° 50 mm
F-307 7° × 5° 65 mm F-610 10° × 8° 65 mm
F-304 4.6° × 3.7° 100 mm F-606 6.2° × 5° 100 mm
Zoom 2× & 4x E-zoom (continuous E-zoom available on specific F-6xxE models)
Spectral Range 7.5 μm to 13.5 μm
Focus Range Athermalized, Focus-Free
Video
Composite Video NTSC or PAL Standard
Video Compression
Two independent channels of streaming MPEG-4, H.264, or M-JPEG;
multiple streams per channel.
Streaming Resolution
NTSC:
D1 (720 × 480), 4SIF (704 × 480), VGA (640 × 480), SIF (352 ×240),
QVGA (320 × 240)
PAL :
D1 (720 ×576), 4CIF (704 × 576), VGA (640 × 480), CIF (352 × 288),
QVGA (320 × 240)
Thermal AGC Modes
Preset AGC modes and manual Brightness (ITT Mean), Contrast (Max
Gain), Sharpness (DDE Gain), and AGC Filter controls.
Thermal AGC Region of
Interest (ROI)
Default, Presets and User definable to insure optimal image quality for
subjects of interest
Image Uniformity Optimization Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
System
Integration
Ethernet Ye s
Serial Control Interfaces RS-232/-422; Pelco D, Bosch
External Analytics Compatible Ye s
