427-0030-00-12, Version 180 March 2018 4
1 F-Series Camera Installation
This manual describes the installation of the F-Series cameras. If you need help during the installation
process, please call to speak with our support experts. All installers and integrators are encouraged to
take advantage of the training offered by FLIR; visit
https://www.flir.com/support-center/training/ for more information.
This manual includes the following topics:
• Installation overview
• Mounting the camera and its components
• Connecting the electronics
• Bench testing the camera
• Basic configuration and operation of the camera
• Camera Specifications
For safety, and to achieve the highest levels of performance from the F-Series camera system, always
follow the warnings and cautions in this manual when handling and operating the camera.
1.1 Warnings and Cautions
Warning!
Caution!
1.2 References
F-SERIES Camera Mechanical Interface Control Document (ICD)
(FLIR Doc # 427-0030-00-19)—available from the FLIR website, provides further details regarding
mechanical dimensions and mounting for the F-Series camera.
If mounting the F-Series camera on a pole, tower or any elevated location, use industry standard
safe practices to avoid injuries.
Except as described in this manual, do not open the F-Series camera for any reason. Disassembly
of the camera can cause permanent damage and will void the warranty.
Be careful not to leave fingerprints on the F-Series camera’s infrared optics.
The F-Series camera requires a power supply of 24 V. Operating the camera outside of the specified
input voltage range or the specified operating temperature range can cause permanent damage.
