Technical data24
Image presentation
Display Built-in widescreen, 4.3 in. LCD, 800 × 480 pixels
Viewfinder Built-in, tiltable OLED, 800 × 480 pixels
Automatic image adjustment Continuous/manual; linear or histogram based
Manual image adjustment
Level/span
Image presentation modes
Image modes IR image, visual image, high sensitivity mode
(HSM)
Measurement
Temperature range
–20°C to +350°C (–4°F to +662°F)
Accuracy
±1°C (±1.8°F) for temperature range (0°C, to
+100°C, +32°F to +212°F) or ±2% of reading for
temperature range (>+100°C, >+212°F)
Measurement analysis
Spotmeter
10
Area 5 boxes with max./min./average
Profile 1 live line (horizontal or vertical)
Difference temperature Delta temperature between measurement func-
tions or reference temperature
Reference temperature Manually set or captured from any measurement
function
Emissivity correction Variable from 0.01 to 1.0 or selected from editable
materials list
Reflected apparent temperature correction Automatic, based on input of reflected
temperature
Measurement corrections Reflected temperature, distance, atmospheric
transmission, humidity, external optics
Set-up
Menu commands
• Level, span
• Auto adjust continuous/manual/semi-
automatic
• Zoom
• Palette
• Start/stop recording
• Store image
• Playback/recall image
Color palettes
• Iron
• Gray
• Rainbow
• Arctic
• Lava
• Rainbow HC
Set-up commands
1 programmable button, overlay recording mode,
local adaptation of units, language, date and time
formats
Storage of images
Storage media Removable SD or SDHC memory card
Image storage capacity 2000 images (JPEG) with post process capability
per GB on memory card
Image storage mode
• IR/visual images
• Visual image can automatically be associated
with corresponding IR image
#T810169; r. AN/42241/42268; en-US
71
