FLIR GFx320 User Manual

Technical data24
Power system
External power operation
AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
vehicle (cable with standard plug, optional)
DC operation 8 to 15.3 V DC, polarity protected (proprietary
protected)
Power 8.5 W typically
Start-up time Typically 7 min. @ 25°C (+77°F)
Environmental data
Operating temperature range –20°C to +50°C (–4°F to +122°F)
Ambient temperature range (certification range for
explosive atmospheres)
–20°C to +40°C (–4°F to +104°F)
Storage temperature range –30°C to +60°C (–22°F to +140°F)
Humidity (operating and storage) IEC 68-2-30/24 h 95% relative humidity +25°C to
+40°C (+77°F to +104°F) (2 cycles)
Explosive (hazardous) environment
• IEC 60079-0:2011
• IEC 60079-11:2011
• IEC 60079-15:2010 (partial)
• IEC 60079-28:2015
• BS EN 60079-0:2012
• BS EN 60079-11:2012
• BS EN 60079-15:2010
• BS EN 60079-28:2015
• ANSI/ISA-12.12.01-2013
• CSA 22.2 No. 213
• ATEX directive 2014/34/EU
Low voltage
73/23/EEC
RoHS 2011/65/EU
WEEE
2012/19/EU
EMC
• The Electromagnetic Compatibility (EMC) Di-
rective 2014/30/EU
• EN61000-6-4 (Emission)
• EN61000-6-2 (Immunity)
• FCC 47 CFR Part 15 class A (Emission)
• EN 61 000-4-8, L5
Encapsulation
IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Safety EN/UL/IEC 60950-1
Physical data
Camera weight, incl. battery 2.80 kg (6.18 lbs.)
Camera weight, excl. battery 2.59 kg (5.71 lbs.)
Battery weight 0.21 kg (0.47 lbs.)
Camera size (L × W × H) 245 × 166 × 164 mm (9.6 × 6.5 × 6.4 in.)
Battery size (L × W × H) 141 × 43 × 28 mm (5.5 × 1.7 × 1.1 in.)
Battery charger size (L × W × H) 158 × 122 × 25 mm (6.2 × 4.8 × 1.0 in.)
Tripod mounting
UNC ¼"-20
Housing material Aluminum, magnesium, silicone
#T810169; r. AN/42241/42268; en-US
73
