JCU II Buttons
432-0012-01-10 Version 110 19
Display Camera and JCU II IP Address
Press the Color button while pushing the joystick forward; the IP address of the JCU II and then
the camera will display on the JCU II screen.
Button Summary
Table 3.1 summarizes the action of each button on the JCU II.
TABLE 3.1 Summary of Button Actions
Button Action
Color Short Cycle through the thermal palettes of the IR thermal imaging sensor.
Power Short
Change JCU II back light illumination level
Power Long
Display JCU II Power Menu
Home Short Return to home position
Home Long Set home to current position
Menu Short Display or exit menus
Scene Short Cycle through four preset scene settings
User 1 Auto Focus (can be reprogrammed)
User 2 Horizontal and Vertical Stabilization on/off (can be reprogrammed)
User 3 Spotlight on/off (can be reprogrammed)
Color + Joystick Forward Display JCU II and camera system IP address
Right Joystick Button When in OSD, select a menu or menu choice
Enable video tracking, then again to select a target
Left Joystick Button When in OSD, back to the last menu or exit OSD menu
Stop tracking a target or disable video tracking
