FLIR MR160 User Manual

FLIR MR160 USER MANUAL Document Identifier: MR160-en-US_AF
2
Table of Contents
1. DISCLAIMERS 4
1.1 Copyright 4
1.2 Quality Assurance 4
1.3 Documentation 4
1.4 Disposal of Electronic Waste 4
2. SAFETY 5
2.1 Safety Notes 5
2.2 Laser Safety 5
3. INTRODUCTION 6
3.1 Key Features 6
4. METER AND MENU ICON DESCRIPTIONS 7
4.1 Meter Parts 7
4.2 Control Buttons 8
4.3 Menu Map and Overview 9
5. OPERATION 10
5.1 Powering the Meter 10
5.1.1 Auto Power OFF (APO) 10
5.2 Moisture Measurements 10
5.2.1 Moisture Measurement Overview 10
5.2.2 Moisture Displays Overview 11
5.2.3 IMAGE Modes 12
5.2.4 MOISTURE Modes 13
5.2.5 Internal Moisture Sensor Measurements (Pinless) 13
5.2.6 External Pin Probe Moisture Measurements 14
5.2.7 Reference Mode Moisture Measurements 15
5.3 Thermal Imager (IR) 15

FLIR MR160 Specifications

General

Type	Electronic hygrometer
Purpose	Indoor
Placement	Hand
Hanger ring	No
Thermometer	Yes
Product color	Black
Humidity measuring range	0 - 100 %
Relative humidity accuracy	5 %
Sustainability certificates	CE
Temperature measurement units	F, K, °C
Display type	Digital
Display diagonal	2.3 \
Display form factor	Square
Power source	Battery
Battery type	Li-Ion
Battery voltage	3.7 V
Number of batteries supported	1
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Package depth	121 mm
Package height	331 mm
Package weight	910 g

Weight and Dimensions

Depth	42 mm
Width	72 mm
Height	140 mm
Weight	300 g
