Technical data24
24.17 FLIR T650sc 45° (incl. Wi-Fi)
P/N: 55904-7923
Rev.: 15417
Imaging and optical data
IR resolution 640 × 480 pixels
Thermal sensitivity/NETD <20 mK @ +30°C (+86°F)
Spatial resolution (IFOV) 1.30 mrad
Image frequency 30 Hz
Focus
Continuous, one shot or manual
Detector data
Image presentation
Display
Built-in touch screen, 4.3 in. wide screen LCD,
800 × 480 pixels
Viewfinder Built-in 800 × 480 pixels
Automatic image adjustment Continuous, histogram based
Manual image adjustment
Linear based; Possible to adjust level/span/max/
min
Image presentation modes
Multi Spectral Dynamic Imaging (MSX)
Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable IR area on visual image
Measurement
Accuracy ±1°C (±1.8°F) or ±1% of reading for limited tem-
perature range,
±2°C (±3.6°F) or ±2% of reading
Measurement analysis
Spotmeter
10
Area
5 areas (boxes or circles) with max./min./average
Profile 1 line profile with max/min temp
Automatic hot/cold detection Auto hot or cold spotmeter markers within area
and profile
Measurement presets
No measurements, Center spot, Hot spot, Cold
spot, User preset 1, User preset 2
Difference temperature Delta temperature between measurement func-
tions or reference temperature
Reference temperature Manually set using difference temperature
Emissivity correction Variable from 0.01 to 1.0 or selected from materi-
als list
Alarm
Measurement function alarm Audible/visual alarms (above/below) on any se-
lected measurement function
Set-up
Set-up commands Define user presets, Save options, Programmable
button, Reset options, Set up camera, Wi-Fi, GPS
& compass, Bluetooth, Language, Time & units,
Camera information
Service functions
Camera software update Use PC software FLIR Tools
#T559880; r.15724/15724; en-US
124
