FLIR T6 series User Manual

Camera parts
8
8.7 Laser pointer
8.7.1 Figure
Figure 8.1 This figure shows the difference in position between the laser pointer and the optical center of
the infrared lens.
WARNING
Do not look directly into the laser beam. The laser beam can cause eye irritation.
Note
The symbol
is displayed on the screen when the laser pointer is on.
Note
The laser pointer may not be enabled in all markets.
8.7.2 Laser warning label
A laser warning label with the following information is attached to the camera:
8.7.3 Laser rules and regulations
Wavelength: 635 nm. Maximum output power: 1 mW.
This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant
to Laser Notice No. 50, dated June 24, 2007.
#T559880; r.15724/15724; en-US
18

FLIR T6 series Specifications

General

Brand	FLIR
Model	T6 series
Category	Thermal cameras
Language	English
