FLIR T6 series User Manual

Working with measurement tools
16
16.1 General
To measure a temperature, you can use one or more measurement tools, e.g., a spot-
meter or a box.
16.2 Adding/removing measurement tools
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
(Measurement).
3. Push the joystick to display a submenu.
• Select
(No measurements) to remove all tools.
• Select
(Center spot) to add a center spot.
• Select
(Hot spot) to add a hot spot detection within a box area.
• Select
(Cold spot) to add a cold spot detection within a box area.
• Select
(User preset 1) to add user preset 1.
• Select
(User preset 2) to add user preset 2.
4. Push the joystick. This will display the measurement tool or the group of preset tools
on the screen.
16.3 Working with user presets
16.3.1 General
A user preset is a measurement tool, or a group of measurement tools, with predefined
characteristics.
16.3.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
(Settings).
3. Push the joystick to display the Settings menu.
4. Select Define user presets and push the joystick.
5. Select Define preset 1 or Define preset 2 and push the joystick. This displays a con-
text menu.
6. Select
(Add measurement).
7. Push the joystick. This displays a submenu.
• Select
(Add spot) to add a spot.
• Select
(Add box) to add a box.
• Select
(Add circle) to add a circle.
• Select
(Add line) to add a line.
• Select
(Add delta) to set up a differential calculation.
8. Push the joystick. This displays the measurement tool on the screen.
#T559880; r.15724/15724; en-US
41
