FLIR T6 series User Manual

Technical data24
24.22 FLIR T620 25° (incl. Wi-Fi)
P/N: 55903-5122
Rev.: 15395
Imaging and optical data
IR resolution 640 × 480 pixels
Thermal sensitivity/NETD <40 mK @ +30°C (+86°F)
Spatial resolution (IFOV) 0.68 mrad
Image frequency 30 Hz
Focus Automatic (one shot) or manual
Detector data
Image presentation
Display Built-in touch screen, 4.3 in. wide screen LCD,
800 × 480 pixels
Automatic image adjustment Continuous, histogram based
Manual image adjustment
Linear based; Possible to adjust level/span/max/
min
Image presentation modes
Multi Spectral Dynamic Imaging (MSX) Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable IR area on visual image
Measurement
Accuracy ±2°C (±3.6°F) or ±2% of reading
Measurement analysis
Spotmeter
10
Area 5 areas (boxes or circles) with max./min./average
Automatic hot/cold detection
Auto hot or cold spotmeter markers within area
Measurement presets No measurements, Center spot, Hot spot, Cold
spot, User preset 1, User preset 2
Difference temperature Delta temperature between measurement func-
tions or reference temperature
Reference temperature Manually set using difference temperature
Emissivity correction Variable from 0.01 to 1.0 or selected from materi-
als list
Alarm
Measurement function alarm Audible/visual alarms (above/below) on any se-
lected measurement function
Set-up
Set-up commands Define user presets, Save options, Programmable
button, Reset options, Set up camera, Wi-Fi, GPS
& compass, Bluetooth, Language, Time & units,
Camera information
Service functions
Camera software update Use PC software FLIR Tools
Storage of images
Image storage mode Simultaneous storage of thermal and digital photo
in same JPEG.
Optional to store digital photo as separate JPEG.
#T559880; r.15724/15724; en-US
145
