CHAPTER 1
Intensifier Description
This manual will help you become familiar with your new Flow International (Flow) equipment. Information was
compiled from the most current information available at the time of publication.
Physical specifications
014623-1 or -3 Long-block intensifier
(Pressure Vessel Application)
Width ..............11.5x12in.(292x304mm)
Length.....................40.5in.(1028.7 mm)
Weight
Intensifier .....................265lb(120kg)
Manifold ........................51lb(23kg)
020070-1 Short-block intensifier (HyperPressure)
Width..................9x6in.(229x152mm)
Length........................42in.(1067 mm)
Weight
Intensifier .....................272lb(124kg)
