Location G
WATER LEAKAGE
Weep holes and locations are identified on the illustrations on Pages 64-65.
Fluid
Likely problem Other possible symptoms
Maintenance
procedure
Kit or parts
needed
Qty. Temp.
Small drip
with each
stroke
Warm
Insufficient torque between high-
pressure gland and outlet adapter
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
Refer to
Small High-Pressure
Components manual
Damaged cone on high-pressure
tubing
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
High-pressure collar not threaded
far enough onto high-pressure
tubing
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
High-pressure tubing not threaded
far enough along length of tubing
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
High-pressure tubing failure or
failed outlet adapter
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
Large flow
with each
stroke
Warm/hot
Insufficient torque between high-
pressure gland and outlet adapter
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
Damaged cone on high-pressure
tubing
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
High-pressure collar not threaded
far enough onto high-pressure
tubing
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
High-pressure tubing not threaded
far enough along length of tubing
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
High-pressure tubing failure or
failed outlet adapter
•
Pump cannot maintain pressure
•
Uneven intensifier stroking
