STRADA GENERATION3 – S5 - INSTALLATION MANUAL
55/66
G. Insert the antenna support (8) from the inside of the housing in the dedicated aperture
in the housing
H. Check the position of the communication antenna strand in the dedicated notches (9)
and in the plastic tie (10).
I. Check the position of the solar panel strand in the plastic tie on the housing and
connect it to the main board (11)
8
9
10
11
