STRADA GENERATION3 – S5 - INSTALLATION MANUAL
61/66
E. Install the 12V / 42Ah battery (3) on its holder (1) and position it so that the strand (4)
is placed on the left terminals positioned at the left.
C. Position the protective cover (5) on the battery by inserting the strands through the
open side to the back of the cover.
D. Connect the adapter strand of the battery (4) to the extension strand located in the
lower compartment.
E. Connect the battery strand (6) to the main board.
6
