Friday, January 06, 2017
Technical Data Center
PO Box 12118
Fort Wayne, IN 46862
FLOWSERVE
3900 COOK BLVD
CHESAPEAKE, VA 23323
PRINTS FOR APPROVAL PACKAGE
Return 'For Approval' prints to the GE Field Sales Engineer or Customer Care Contact. The order is on
hold until prints are approved and returned. When approved prints are received by GE, current
leadtimes will apply.
Approved by: ________________________________________________ Date: ________________
Visit us: www.gemotors.com
Page 2 of 9
Customer Order / Item:
246453
Sales Order No:
5200020871
Customer Part:
None
Order Line No:
2.1
Marks:
PROJECT# 1244763-2 CARTER & VERPLANCK
MODEL NUMBER:
5KS405SAA2177 Estimated Weight:
1480 Lbs
Outline Drawing:
239C6400SW
Time Rating:
CONT
Connection Diagram:
GEM2034E-FIG7
Enclosure:
TEFC
Instruction Book:
GEI-56128
Encl Construction:
X$D
Design Code:
40BD1066A
Ambient Max(°C):
40
Type:
KS
Alt Ambient Max(°C):
65
Frame:
405T
Insulation Class:
H
Phases:
3
NEMA Design:
B
Poles:
4
Nominal Efficiency:
95.8%
Output Power:
100HP 74.6KW
Guaranteed Efficiency:
95.4%
RPM:
1785
3/4 Load Efficiency:
95.8%
Voltage:
460
KVA Code:
G
Hertz:
60
Max KVAR:
31.1
Amps - FL:
118.0
Power Factor:
83.0
Service Factor:
1.15
Bearing - DE:
6316ZC3S0
Alt Service Factor:
1.00
Bearing - ODE:
6316ZC3S0
Enclosure is Totally Enclosed Fan-Cooled
Stamped Nameplate Notes:
HTR LDS HE1-HE2 115V 100W
THERMOSTAT LEADS TM1-TM2 ALARM
INVERTER DUTY PER NEMA MG1 PART 31
ALTERNATE RATING FOR PWM CONTROL:1.0SF 40C AMBIENT
VAR TORQUE RANGE 0-60 HZ
Additional Information:
4P - T EXTN
PAINTED FRAME ID & SHAFT,
FAN COVER INSIDE & ODE E/S OUTSIDE
1260 CU IN - 4.00" NPT WITH TERMINAL BOARD
INPRO SEAL BOTH ENDS
OIL RESISTANT SLEEVING ON LEADS
AUTO GREASE RELIEF FITTING
(3) N.O. CL.F ALARM TSTAT LDS TO MAIN CONDUIT BOX
