45
ISO VG 32
BP
Castrol
Chevron
Esso
Energol THB 32 (ISO)
Perfecto T32
OC Turbine Oil 32
Nuto H32
Gulf
Mobil
Shell
Texaco
Harmony 32
DTE Oil Light
Turbo T32
Regal Oil R & O 32
4.6 Trico Oiler Setting
Initial fill via top of housing, using overflow plug to establish correct level (see Section 4.1
illustration).
Release thumb screw and remove bottle. Establish a measurement from the centre line of the oiler
connection in bearing housing to the upper cross arm of 6 mm (.24"); this can be obtained by
completely screwing down the lower arm as illustrated below.
TRICO OILER
Fill bottle with recommended oil and install on holder. Remove and fill bottle as many times as is
required to fill the bearing housing up to the cross arm level and no air bubbles appear in the
bottle.
Remove bottle and ascertain that the oil level is 6 mm (.24") from the centre line of oiler
connection. Adjust upper cross arm as required and lock in place with lower arm.
