46
4.7 Bearing Housing Oil Fill Capacities
Bearing Housing Number * Bearing Designation Oil Fill Capacities (litres)
Slinger Oil Ring
G040B159 7308
1.51 1.13
G050B159 7311
1.34
0.85
G070B159 7314
1.83
1.02
G090B159 7315 4.43 2.82
7316
4.17 2.60
* The bearing housing size can be identified from the identifying marks cast on the housing on the
horizontal centre line in the opposite side to the oiler.
4.8 Bearing Housing Oil Limitations
Maximum Oil Temperature
180°F
82°C
Minimum Oil Temperature At Start Up 60°F
15.6°C
Desirable Operating Temperature 140-160°F
60-71°C
Housing Capacity 3 Pints
1.42 Litres
Oil Level Above Oil Connection Centre line
6 mm
FOR MORE DETAILS REFER TO THE APPENDIX ON THE LAST PAGE OF THE IOM MANUAL
AND THE LUBRICANT LIST
