Actuator Weights
The approximate L120 actuator weights are provided below:
Table 3.1 – Actuator weights
Actuator
Size
Control Types
Drive 1 Weight (lb./kg) Drive 2 Weight (lb./kg)
Top HW Side HW Top HW Side HW
lb. kg lb. kg lb. kg lb. kg
L120-10
NCU 100 45 112 51 107 49 119 54
BIC 115 52 127 58 122 55 134 61
CLAMSHELL 140 64 152 69 147 67 159 72
L120-20
NCU 140 64 158 72 153 69 171 78
BIC 155 70 173 78 168 76 186 84
CLAMSHELL 180 82 198 90 193 88 211 96
L120-40
NCU 190 86 216 98 212 96 238 108
BIC 205 93 231 105 227 103 253 115
CLAMSHELL 230 105 256 116 252 114 278 126
Note: Approximate weights are based on standard explosion-proof construction, with the largest
three-phase motor available for the model size.
