Flowserve Logix 3000MD Series User Manual

Logix 3200IQ Digital Positioner FCD LGENTB0059-01 – 10/09
10
Specifications for Logix 3400MD
Power Supply
Two-wire, 9-32 VDC
FF compatible
IS Fisco compliant
Communications FF Protocol ITK 4.6x, 5.0
Operating Current 23 mA
Maximum Voltage 36.0 VDC
Table I: Electrical Specifications
Operating Temperature
Range
Standard
-40° to 176°F
(-40° to 80°C)
Transport and Storage
Temperature Range
-40° to 176°F (-40° to 80°C)
Operating Humidity 0 - 100% non-condensing
Note: The air supply must conform to ISA Standard ISA 7.0.01 (a
dew point at least 18 degrees Fahrenheit below ambient tempera-
ture, particle size below five microns—one micron recom-
mended—and oil content not to exceed one part per million).
Table II: Environmental Conditions
Deadband <0.1% full scale
Repeatability <0.05% full scale
Linearity <0.5% (rotary), <0.8%, (sliding stem) full scale
Air Consumption <0.3 SCFM (0.5 Nm
3
/hr) @ 60 psi (4 bar)
Air Supply 30-150 psig (ISA 7.0.0.1 compliant)
Air Delivery 12 SCFM @ 60 psi (0.27 Cv)
Table IV: Positioner Specifications
Table I: Electrical Specifications
Power Supply
Two-wire, 4-20 mA
10.0 to 30.0 VDC
Compliance Voltage 10.0 VDC @ 20 mA
Effective Resistance
495 Ω @ 20 mA Typical
Add 20 Ω when HART communication
active
Communications HART Protocol ITK 5,6
Minimum Operating
Current
3.6 mA without AO board
3.7 mA with AO board
Maximum Voltage 30.0 VDC
Table II: Environmental Conditions
Operating Temperature
Range
Standard
-4° to 176°F
(-20° to 80°C)
Low
-40° to 176°F
(-40° to 80°C)
Transport and Storage
Temperature Range
-40° to 176°F (-40° to 80°C)
Operating Humidity 0 - 100% non-condensing
Note: The air supply must conform to ISA Standard ISA 7.0.01
(a dew point at least 18 degrees Fahrenheit below ambient
temperature, particle size below five microns—one micron recom-
mended—and oil content not to exceed one part per million).
Table III: Physical Specifications
Housing
Material
Cast, powder-painted aluminum or stainless steel
Soft Goods Buna-N / Florosilicone
Weight
8.3 pounds (3.9 kg) aluminum
20.5 pounds (9.3 kg) stainless steel
Table IV: Positioner Specifications
Deadband <0.1% full scale
Repeatability <0.05% full scale
Linearity <0.5% (rotary), <0.8%, (sliding stem) full scale
Air Consumption <0.3 SCFM (0.5 Nm
3
/hr) @ 60 psi (4 bar)
Air Supply 30-150 psig (ISA 7.0.0.1 compliant)
Air Delivery 12 SCFM @ 60 psi (0.27 Cv)
Housing
Material
Cast, powder-painted aluminum or stainless steel
Soft Goods Buna-N / Florosilicone
Weight
8.3 pounds (3.9 kg) aluminum
20.5 pounds (9.3 kg) stainless steel
Table III: Physical Specifications
The Logix 3000MD Positioner Specifications
Specifications for Logix 3200MD

Flowserve Logix 3000MD Series Specifications
