Logix 3200IQ Digital Positioner FCD LGENTB0059-01 – 10/09
14
Logix 3400MD Hazardous Area Certifications
Notified Body
Certification
Option
Approval Entity Parameters Temperature Code
Enclosure
Rating
-01
Explosionproof:
Class I, Div 1, Groups B,C,D
Dust Ignition Proof:
Class II, III, Div 1, Groups EFG
(See Warning No. 1, 2)
Not Applicable T6 T
amb
≤ = 60ºC
NEMA
4X
-02
Intrinsically Safe:
Class I, II, III, Div 1, Groups A,B,C,D
Class 1, Zone 0, AEx ia IIC
(See Warning No. 2,3)
Entity Fisco
Parameters Parameters
Ui = 24 Vdc Ui = 17.5 Vdc
Ii = 250mA Ii = 380mA
Pi = 1.2 W Pi = 5.32W
Ci = 3300pF Ci = 3300 pF
Li = 10mH Li = 10mH
(refer to control drawing No.
234401)
T4 T
amb
≤ = 60ºC NEMA
4X
-02
Non-Incendive:
Class I, II, III, Div 2, Groups A,B,C,D
(See Warning No. 2)
Install per NEC Article
501-4 when barriers are
not used.
T6 T
amb
-20
0
to 60
0
C
NEMA
4X
-01
Explosionproof:
Class I, Div 1, Groups B,C,D
Class II, Div 1, Groups E,F,G
Class III
Ex d IIB+H2
(See Warning No. 2)
Not Applicable -20º ≤ Ta ≤ +55ºC
Type
4X
ATEX
-07
Explosionproof (Flameproof):
II 2 GD
Ex d IIB + H
2
Ex tD A21 T95ºC
(See Warning No. 1, 2)
Not Required
T5 (T =-40ºC to +
80ºC)
IP65
-04 or -15
Intrinsically Safe:
II 1 G
Ex ia IIC
(See Warning No. 2, 3)
Ui = 30 Volts
Ii = 100mA
Pi = 800mW
Ci = 30 nF
Li = 0
Co = 36 nF
T4 (T
amb
-40ºC to + 85ºC)
T5 (T
amb
-40ºC to + 55ºC)
IP65
-04
Non-Incendive:
II 3 G
Ex nL nA IIC
(See Warning No. 2)
Not Required
T4 T
amb
-40ºC to + 85ºC)
T5 T
amb
-40ºC to + 55ºC)
IP65
GOST
Explostionproof (Flameproof):
1Ex d IIBT5/H
2
X
(See Warning No. 1,2)
Not Required T5 (-50
0
C ≤Ta ≤ +55
0
C) IP65
Intrinisically Safe:
0Ex ia IICT4X
Ui = 24 Vdc
Ii = 250mA
Pi = 1.2W
Ci = 330 pF
Li = 10 mH
T4 (T
amb
-50
0
C to + 60
0
C) IP65
IECEx
-21
Intrinsically Safe:
Ex ia IIC
(See Warning No. 2, 3)
Ui = 24 Vdc
Ii = 250mA
Pi = 01.2W
Ci = 330 pF
Li = 10 mH
T4 (T
amb
-20ºC to + 60ºC) IP65
-06
Explosionproof (Flameproof):
BR-Ex d IIB + H
2
(See Warning No. 1, 2)
Not Required T5 (-40ºC≤ Ta ≤ + 55ºC) IP65
-06 or -22
Intrinsically Safe:
BR- Ex ia IIC
(See Warning No. 2, 3)
Ui = 24 Vdc
Ii = 250mA
Pi = 1.2W
Ci = 3300 mF
Li = 10 mF
T5 (-40ºC≤ Ta ≤ + 55ºC)
T4 (-40ºC≤ Ta ≤ + 85ºC)
IP65
GOST R
GOST K, GOST K GGTN
WARNINGS:
1. In order to maintain the explosionproof certifications do not remove or loosen covers during operation.
2. To avoid the possibility of static discharge clean only with a damp cloth.
3.
The positioner must be connected to suitable rated intrinsically safe equipment, and must be installed in accordance with intrinsically safe installation
standards.
®
