Flowserve Logix 3000MD Series User Manual

Logix 3000MD Series Digital Positioner FCD LGENTB0059-01 – 10/09
15
Logix 3200MD Hazardous Area Certifications
Notified Body
Certification
Option
Approval Entity Parameters Temperature Code
Enclosure
Rating
-10
Explosionproof:
Class I, Div 1, Groups B,C,D
Dust Ignition Proof:
Class II, III, Div 1, Groups EFG
(See Warning No. 1, 2)
Not Applicable T6 T
amb
≤ = 60ºC
NEMA
4X
-10
Intrinsically Safe:
Class I, II, III, Div 1, Groups A,B,C,D
Class 1, Zone 0, AEx ia IIC
(See Warning No. 2,3)
Vmax = 30 Volts
Imax = 100mA
Pmax = 800mW
Ci = 30 nF
Li = 0
(refer to control drawing No.
198736)
T4 T
amb
≤ = 85ºC
T5 T
amb
≤ = 55ºC
NEMA
4X
-10
Non-Incendive:
Class I, Div 2, Groups A,B,C,D
(See Warning No. 2)
Install per NEC Article
501-4 when barriers are
not used.
T4 T
amb
≤ = 85ºC
T5 T
amb
≤ = 55ºC
NEMA
4X
-10
Explosionproof:
Class I, Div 1, Groups B,C,D
Class II, Div 1, Groups E,F,G
Class III
(See Warning No. 1, 2)
Not Applicable -25º ≤ Ta ≤ +40ºC
Type
4X
10
Intrinsically Safe:
Class I, II, III, Div 1, Groups A,B,C,D
(See Warning No. 2, 3)
Vmax = 30 Volts
Imax = 100mA
Pmax = 800mW
Ci = 30 nF
Li = 0
(refer to control drawing No.
198736)
T4 T
amb
≤ = 80ºC
Type
4X
10
Non-Incendive:
Class I, II, Div 2, Groups A,B,C,D
(See Warning No. 2)
Not Required T4 T
amb
≤ = 80ºC
Type
4X
ATEX
-28
Explosionproof (Flameproof):
II 2 GD
Ex d IIB + H
2
Ex tD A21 T95ºC
(See Warning No. 1, 2)
Not Required T5 (T = -40ºC to + 80ºC) IP65
-28
Intrinsically Safe:
II 1 G D
Ex ia IIC
Ex iaD 20 T95
0
C
(See Warning No. 2, 3)
Ui = 30 Volts
Ii = 100mA
Pi = 800mW
Ci = 30 nF
Li = 0
Co = 36 nF
T4 (T
amb
-40ºC to + 85ºC)
T5 (T
amb
-40ºC to + 55ºC)
(Ta = -40
0
C to + 80
0
C)
IP65
-28
Non-Incendive:
II 3 G
Ex nL nA IIC
Ex tD A22 T95
0
C
(See Warning No. 2)
Not Required
T4 T
amb
(-40ºC to + 85ºC)
T5 T
amb
(-40ºC to + 55ºC)
(Ta = -40
0
C to + 80
0
C)
IP65
IECEx
-16
Explosionproof (Flameproof):
Ex d IIB + H
2
(See Warning No. 1, 2)
Not Required
T5 (T
amb
-20ºC to + 55ºC)
T5 (T
amb
-40ºC to + 80ºC)
IP65
-21
Intrinsically Safe:
Ex ia IIC
(See Warning No. 2, 3)
Ui = 30 Vdc
Ii = 100mA
Pi = 0.8W
Ci = 30 nF
Li = 0
T4 (T
amb
-40ºC to + 85ºC) IP65
GOST
Explosionproof (Flameproof):
1Ex d IIBT5/H
2
X
(See Warning No. 1,2)
Not Required T5 (-50
0
C ≤Ta ≤ +55
0
C) IP65
Intrinisically Safe:
0Ex ia IICT4X
0Ex ia IICT5X
(See Warning No 2,3)
Ui = 30 Volts
Ii = 100mA
Pi = 800mW
Ci = 30 nF
Li = 0
T4 (T
amb
-50
0
C to + 60
0
C) IP65
-06
Explosionproof (Flameproof):
BR-Ex d IIB + H
2
(See Warning No. 1, 2)
Not Required T5 (-40ºC ≤ Ta ≤ + 80ºC) IP65
-06
Intrinsically Safe:
BR- Ex ia IIC
(See Warning No. 2, 3)
Ui = 30 Vdc
Ii = 100mA
Pi = 800mW
Ci = 30 nF
Li = 0
Co = 36 nF
T5 (-40ºC ≤ Ta ≤ + 55ºC)
T4 (-40ºC ≤ Ta ≤ + 85ºC)
IP65
®
