Flowserve Logix 3400MD User Manual

19
Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
flowserve.com
Table VII: Status and Conditions
Code
Meaning
Error
Code
Sticker
Line
Sticker Text
GGGG Normal Operation 255 1 Normal Operation
GGGY MPC Active 13 2
Tight shutoff (MPC)
active*
GGYG Local Interface Disabled 14 3
Local Interface
Disabled*
GGYY Digital Command Mode 2 4
Digital Command
mode*
GGRR Squwak Mode 3 5 Squawk mode*
GYGG Position Upper Limit 11
6
Upper or lower
position alert*
GYGG Position Lower Limit 12
GYGY Soft Stop Upper Limit 9
7
Soft stop position
reached*
GYGY Soft Stop Lower Limit 10
GRGG Valve Cycles Warning 22
8
Travel or cycle limit
reached*
GRGG Valve Travel Warning 23
GRGG Spool Cycles Warning 50
GRGG Spol Travel Warning 51
YGGY Signature in Progress 5 9
Signature in
progress
YGGR Initializing 0 10
Initialization in
progress
YGYG Stroke Cal in Progress 24
11
Calibration in
progress
YGYG
Command Loop Cal in
Progress
25
YGYG Pressure Cal in Progress 26
YGYG
Analog Output Cal in
Progress
27
YGYG Setting Inner Loop Offset 28
YGYY Joc Command Mode 4 12
Local jog command
mode
YGYR
Jog Calibration Set 100
Position
62 13
Jog cal waiting ->
Set 100% pos.
YYGG Temp. High Warning 32
14
Positioner tempera-
ture warning
YYGG Temp. Low Warning 33
YYGY Port 1 Value Out of Range 43
15
Pressure out of
range warning
YYGY Port 2 Value Out of Range 44
YYGY Port 1 Range Too Small 45
YYGY Port 2 Range Too Small 46
YYGR
Supply Pressure High
Warning
41 16
Supply pressure
high warning* **
YYYG
Supply Pressure Low
Warning
42 17
Supply pressure low
warning* **
YYYY Actuation Ratio Warning 16 18
Actuation ratio
warning* **
YRGG Spool Sticking Warning 48 19
Pilot relay response
warning*
